DPSR Series round cylinder
Piston diameter :8,10,12,16,20,25,32,40,50,63
Product characteristics
• Stainless steel piston rod
• Low pressure for operating and quick response
• Good running performance and long service life
• Wide range of accessories, enabling the cylinder to be installed virtually anywhere
• φ8 ～ φ25 is to ISO 6432 and its variants are corresponded with ISO or DIN.
• Low pressure for operating and quick response
• Good running performance and long service life
• Wide range of accessories, enabling the cylinder to be installed virtually anywhere
• φ8 ～ φ25 is to ISO 6432 and its variants are corresponded with ISO or DIN.
